Medical Equipment Mobile X-ray Camera High Frequency Mobile Digital Portable X-ray Machine

Medical Equipment China High Frequency Digital Radiography Portable 100mA Mobile X-ray MachineFeatures:1. With high frequency inverter to emit high quality X-ray and low dose on  skin, and ensure excellent definition and contrast of pictures. 2. With techniques of KV analog closed loop control, mAs digital closed loop

Featured Products

Medical Equipment China High Frequency Digital Radiography Portable 100mA Mobile X-ray Machine
Medical Equipment Mobile X-ray Radiography High Frequency Mobile Digital Portable X Ray Machine

Features:

1. With high frequency inverter to emit high quality X-ray and low dose on  skin, and ensure excellent definition and contrast of pictures.

2. With techniques of KV analog closed loop control, mAs digital closed loop control and micro-processing real-time control to ensure precision and repeatability of the dose.

3. With kV, mAs two button adjustment, LCD display, multifunction of safety guard.

4. With 50 preset exposure programs, and can be modified and stored by the user for convenient operation.

5. With a high-quality knockdown X-ray generator to reduce irradiation, which is much safer to environment and operator.

6. With a symmetrical beam applicator to adjust the X-ray field and a collimator lamp to locate the filed to ensure accurate radiograph.


Specifications:

Item Specification
1. High voltage generator
1.1standard output power:5.6kW
1.2mA range:10-100mA
1.3Tube voltage range:40-125kV
1.4mAs range :0.1-200mAs
1.5Load time range:0.002s~4s
1.6High voltage transformer structure:The power frequency
2.X-ray tube
2.1Focus range:0.6/1.8mm
2.2Anode types: fixed anode
2.3The maximum voltage:125kV
2.4Anode angle 15°
2.5The inherent filtration:0.6mm Al/75kV
3. Collimator
3.1The inherent filtration:1 mm Al /70 kV;
3.2Collimator is equipped with LED lights(Bright 30S are automatically extinguished)
3.3Collimator is built into measuring ruler
 4. The tube bracket structure
4.1SID: 330 ~ 1650mm
4.2Size after folding:1060*400*400mm
4.3weight:32KG
5. Detector(iRay)
5.1WIFI connection, Amorphous Silicon oxide ,whole panel technology
5.2The effective camera size of the detector:350mm×430mm
5.3Pixel size:150 µm
5.4Gathering matrix:≥2304×2800pixels
5.5Spatial resolution≥3.4lp/mm
5.6Pixel gray level:≥14bit
5.7Detector cooling mode: natural cooling
6. Digital image workstation
6.1CPU frequency:CORE i3
6.2Memory capacity:4GB
6.3Hard drive capacity:500 GB
6.464 bit Windows operation system
7. Image acquisition software
7.1Patient registration: acquisition, find the patient data, to prepare for the photography
7.2Images display, image analysis, processing and output
7.3Data management: managing patient data, leading in, leading out , batch file, etc in accordance with DICOM3.0,5.4AH
7.4System diagnosis: monitoring system status, diagnosis of the system fault
8. The machine parameters
9.1Appearance size
9.1.1Whole machine width:240 mm
9.1.2Whole machine length:440 mm
9.1.3Whole machine height:236 mm
9.2Whole weight(no detector):18kg
9. Options
10.1Wireless network data transmission(WIFI)
10.2Choose a chest rack
10.3The selection of moving flat bed


Certificate:
Medical Equipment Mobile X-ray Radiography High Frequency Mobile Digital Portable X Ray Machine

Package:
Medical Equipment Mobile X-ray Radiography High Frequency Mobile Digital Portable X Ray Machine

Shipping:
Medical Equipment Mobile X-ray Radiography High Frequency Mobile Digital Portable X Ray Machine

Our Service:
Medical Equipment Mobile X-ray Radiography High Frequency Mobile Digital Portable X Ray Machine
Medical Equipment Mobile X-ray Radiography High Frequency Mobile Digital Portable X Ray Machine
